ZS/ZSS Rectifier Transformer

Product Introduction

• The ZS/ZSS series rectifier transformers are core power transformers for rectifier equipment, specifically designed for industrial applications that require conversion of AC power to DC power. The primary side receives three-phase AC input, while the secondary side outputs DC through rectifying elements, providing a stable and reliable DC power supply for rectifier systems.
• ZS/ZSS rectifier transformers are widely used in metallurgy, chemical processing, electrolysis, power plant excitation, locomotive traction, and DC drive systems, making them a critical component of DC power supply networks.

Application Scenarios

• Chemical Industry: Electrolysis, chemical synthesis, and fine chemical equipment
• Metallurgical Industry: DC smelting, electrolysis smelting, and electric furnace operations
• Locomotive Traction & DC Drive Systems
• Power Plant Excitation Systems
• Other Industrial DC Power Supply Equipment

Installation Requirements & Environmental Conditions

• Installation Type: Outdoor
• Altitude: ≤ 1200 m
• Seismic Resistance: Earthquake intensity 8
• Ambient Temperature: -35°C to +40°C
• Solar Radiation: 0.1 W/cm² at wind speed 0.5 m/s
• Relative Humidity: Daily average ≤ 95%, monthly average ≤ 90% (at 25°C)
• Ice Thickness: ≤ 25 mm
• Maximum Wind Speed: ≤ 35 m/s
• Note: Transformers can be customized to operate under special service conditions according to user requirements.

Advantages

• Low loss, low noise
• High overload capacity and strong impact resistance
• Strong short-circuit withstand capability
• Safe and reliable power supply
• Designed for high performance, ZS/ZSS rectifier transformers convert three-phase AC power from the grid to the required rectified AC voltage, which is then converted to DC by the rectifier, meeting the precise DC power requirements of various industrial equipment.
